How to Convert A TensorFlow Model to ONNX Format?

14 minutes read

Converting a TensorFlow model to the ONNX (Open Neural Network Exchange) format enables interoperability between different deep learning frameworks. Here's a step-by-step guide on how to accomplish it:

  1. Install the necessary tools: Install TensorFlow: Follow the TensorFlow installation instructions specific to your system. Install ONNX: Use pip to install the ONNX package by running the command pip install onnx. Install tf2onnx: Run the command pip install tf2onnx to install the tf2onnx converter.
  2. Save the TensorFlow model: First, ensure that you have a trained TensorFlow model that you want to convert. Save the TensorFlow model and its weights to a file using the model.save() function. This will create a SavedModel directory.
  3. Convert the TensorFlow model to ONNX format: Use tf2onnx converter to convert the SavedModel directory to an ONNX model. Run the command: python -m tf2onnx.convert --saved-model /path/to/tensorflow_model --output /path/to/onnx_model.onnx
  4. Verify the ONNX model: Load the ONNX model in Python using the onnx.load() function. Verify that the conversion succeeded without any errors.
  5. Utilize the ONNX model in other frameworks: You can use the converted ONNX model in frameworks like PyTorch, Caffe2, or Microsoft Cognitive Toolkit without compatibility issues.


By following these steps, you can convert a TensorFlow model to the ONNX format, allowing you to leverage the model in various deep learning frameworks.

Best TensorFlow Books to Read in 2024

1
Hands-On Machine Learning with Scikit-Learn, Keras, and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems

Rating is 5 out of 5

Hands-On Machine Learning with Scikit-Learn, Keras, and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems

2
Deep Learning with TensorFlow and Keras: Build and deploy supervised, unsupervised, deep, and reinforcement learning models, 3rd Edition

Rating is 4.9 out of 5

Deep Learning with TensorFlow and Keras: Build and deploy supervised, unsupervised, deep, and reinforcement learning models, 3rd Edition

3
Hands-On Machine Learning with Scikit-Learn, Keras, and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems

Rating is 4.8 out of 5

Hands-On Machine Learning with Scikit-Learn, Keras, and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems

  • Use scikit-learn to track an example ML project end to end
  • Explore several models, including support vector machines, decision trees, random forests, and ensemble methods
  • Exploit unsupervised learning techniques such as dimensionality reduction, clustering, and anomaly detection
  • Dive into neural net architectures, including convolutional nets, recurrent nets, generative adversarial networks, autoencoders, diffusion models, and transformers
  • Use TensorFlow and Keras to build and train neural nets for computer vision, natural language processing, generative models, and deep reinforcement learning
4
TensorFlow in Action

Rating is 4.7 out of 5

TensorFlow in Action

5
Learning TensorFlow: A Guide to Building Deep Learning Systems

Rating is 4.6 out of 5

Learning TensorFlow: A Guide to Building Deep Learning Systems

6
TinyML: Machine Learning with TensorFlow Lite on Arduino and Ultra-Low-Power Microcontrollers

Rating is 4.5 out of 5

TinyML: Machine Learning with TensorFlow Lite on Arduino and Ultra-Low-Power Microcontrollers

7
Hands-On Machine Learning with Scikit-Learn and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems

Rating is 4.4 out of 5

Hands-On Machine Learning with Scikit-Learn and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems

8
Python Machine Learning: Machine Learning and Deep Learning with Python, scikit-learn, and TensorFlow 2, 3rd Edition

Rating is 4.3 out of 5

Python Machine Learning: Machine Learning and Deep Learning with Python, scikit-learn, and TensorFlow 2, 3rd Edition

9
Deep Learning with TensorFlow 2 and Keras: Regression, ConvNets, GANs, RNNs, NLP, and more with TensorFlow 2 and the Keras API, 2nd Edition

Rating is 4.2 out of 5

Deep Learning with TensorFlow 2 and Keras: Regression, ConvNets, GANs, RNNs, NLP, and more with TensorFlow 2 and the Keras API, 2nd Edition

10
TensorFlow Developer Certificate Guide: Efficiently tackle deep learning and ML problems to ace the Developer Certificate exam

Rating is 4.1 out of 5

TensorFlow Developer Certificate Guide: Efficiently tackle deep learning and ML problems to ace the Developer Certificate exam

11
Artificial Intelligence with Python Cookbook: Proven recipes for applying AI algorithms and deep learning techniques using TensorFlow 2.x and PyTorch 1.6

Rating is 4 out of 5

Artificial Intelligence with Python Cookbook: Proven recipes for applying AI algorithms and deep learning techniques using TensorFlow 2.x and PyTorch 1.6


What are the common challenges faced when converting a TensorFlow model to ONNX?

When converting a TensorFlow model to ONNX, several common challenges can be encountered:

  1. Operator support: TensorFlow and ONNX can have different sets of supported operators. When converting a model, some TensorFlow operators may not have a direct equivalent in ONNX, leading to potential operator compatibility issues.
  2. Custom operations: If a TensorFlow model contains custom operations or custom layers that are not part of the ONNX specification, these operations may not be supported during the conversion process. Such custom operations will need to be manually implemented or mapped in ONNX.
  3. Dynamic shapes: TensorFlow allows for dynamic shapes, where the input and output shapes of a model can vary during runtime. ONNX, on the other hand, usually requires static shapes to be defined. If a TensorFlow model utilizes dynamic shapes, it may need to be modified or reshaped to have static shapes for ONNX conversion.
  4. Control flow operations: TensorFlow supports control flow operations like loops and conditionals, while ONNX has limited support in this area. If a TensorFlow model contains complex control flow operations, they may need to be transformed or redesigned before conversion to ONNX.
  5. Quantization and data types: TensorFlow and ONNX may have different default data types and quantization techniques. Issues related to data types and quantization can arise during the conversion process, as the underlying numerical precision and range may affect the model's behavior.
  6. Version compatibility: TensorFlow and ONNX evolve independently, which can lead to version compatibility issues during the conversion process. The TensorFlow model format and ONNX specifications may have differences that require appropriate version handling or converter updates.
  7. Backend constraints: The target deployment environment may have specific constraints on the runtime and hardware optimizations. The converted ONNX model may need further optimization and performance tuning to effectively utilize the available resources.


To mitigate these challenges, it is essential to thoroughly review the compatibility between the TensorFlow model and the targeted ONNX version, with a focus on supported operators, data types, control flow operations, and any custom or dynamic elements in the model. Additionally, it's important to consider the intended deployment environment and any limitations or optimizations required for optimal performance.


How to use the TensorFlow2ONNX converter tool?

To use the TensorFlow2ONNX converter tool, follow these steps:

  1. Install the TensorFlow2ONNX package using pip: $ pip install tf2onnx
  2. Convert the TensorFlow model to ONNX format by running the convert.py script provided by TensorFlow2ONNX. The basic syntax of the command is: $ python -m tf2onnx.convert \ --input \ --output \ --inputs \ --outputs Replace the following placeholders: : Path to the TensorFlow model (.pb file) or folder containing the model. : Path where the converted ONNX model should be saved. : Comma-separated names of the input nodes in the TensorFlow model. : Comma-separated names of the output nodes in the TensorFlow model. For example, if you want to convert a TensorFlow model located at model.pb, with input node named input and output node named output, and save the resulting ONNX model as converted_model.onnx, run the following command: $ python -m tf2onnx.convert \ --input model.pb \ --output converted_model.onnx \ --inputs input \ --outputs output Note that TensorFlow2ONNX also supports various other parameters to fine-tune the conversion process. Refer to the documentation for more details.
  3. After successful conversion, you should find the ONNX model saved at the specified . The ONNX model is now ready for use in any ONNX-compatible model execution framework.


How to convert a TensorFlow model to ONNX format using TensorFlow Lite?

To convert a TensorFlow model to ONNX format using TensorFlow Lite, you can follow these steps:

  1. Install the required dependencies: TensorFlow 2.x ONNX ONNX-TF (to convert from TensorFlow to ONNX) TF2ONNX (to convert from TensorFlow 2.x to ONNX)
  2. Convert the TensorFlow model to TensorFlow Lite format: Load and convert the TensorFlow model to TensorFlow Lite format using the tf.lite.TFLiteConverter.from_saved_model function. Specify the input and output shape and names, if required. Save the converted TensorFlow Lite model to a file.
  3. Convert the TensorFlow Lite model to ONNX format: Convert the TensorFlow Lite model to ONNX format using the --input flag in the TF2ONNX package. Specify the TensorFlow Lite file path and the output ONNX file path.


Here's an example code snippet to demonstrate the conversion process:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
import tensorflow as tf
import tf2onnx

# Step 1: Install the dependencies

# Step 2: Convert TensorFlow model to TensorFlow Lite format
tf_model = "/path/to/tf_model_directory"
tflite_model = "/path/to/output/tflite_model.tflite"

converter = tf.lite.TFLiteConverter.from_saved_model(tf_model)
converter.optimizations = [tf.lite.Optimize.DEFAULT]
converter.target_spec.supported_types = [tf.float16]
tflite_model = converter.convert()

with open(tflite_model, "wb") as f:
    f.write(tflite_model)

# Step 3: Convert TensorFlow Lite model to ONNX format
tflite_model = "/path/to/output/tflite_model.tflite"
onnx_model = "/path/to/output/onnx_model.onnx"

tf2onnx.convert.from_tensorflow_frozen_model(
    tflite_model,
    input_names=['input'],
    output_names=['output'],
    opset=13,
    output_path=onnx_model
)


Make sure to replace "/path/to/tf_model_directory" with the actual path to your TensorFlow model directory, "/path/to/output/tflite_model.tflite" with the desired path to save the TensorFlow Lite model, and "/path/to/output/onnx_model.onnx" with the desired path to save the ONNX model.


What is a SavedModel in TensorFlow?

A SavedModel in TensorFlow is a file format that allows users to save and load models in TensorFlow. It includes both the model's architecture and its trained weights and is designed to be platform-independent, meaning it can be used to deploy models in different programming languages and on various devices. The SavedModel format is useful for sharing models, deploying models in production environments, and reusing pre-trained models in different projects. It also enables exporting models for TensorFlow Serving, TensorFlow Lite, TensorFlow.js, and other TensorFlow runtime environments.
